罗茨鼓风机作为容积式风机，因结构简单、风压稳定等特点，在污水处理、水产养殖等领域应用广泛。选型需综合工况需求、设备参数及运行成本，避免能耗过高或无法满足生产要求，实现高效稳定运行。

　　Roots blower, as a positive displacement fan, is widely used in fields such as sewage treatment and aquaculture due to its simple structure and stable air pressure. The selection should take into account the working conditions, equipment parameters, and operating costs to avoid excessive energy consumption or inability to meet production requirements, and achieve efficient and stable operation.

　　风量是选型核心，需与实际需求匹配并预留余量。风量指单位时间输送气体体积，按生产工艺耗气量确定，同时预留 10%-20% 应对工况波动。如污水处理曝气系统按水池容积等计算风量，气力输送需考虑物料特性与距离。风机风量与转速成正比，同一型号转速越高风量越大，但超额定转速会导致电机过载，需在额定范围内调整。

　　Air volume is the core of selection, which needs to be matched with actual needs and reserved with margin. Airflow refers to the volume of gas transported per unit time, determined based on the gas consumption of the production process, while reserving 10% -20% to cope with fluctuations in operating conditions. If the aeration system for sewage treatment calculates the air volume based on the volume of the water tank, pneumatic conveying needs to consider material characteristics and distance. The air volume of the fan is proportional to the speed, and the higher the speed of the same model, the greater the air volume. However, exceeding the rated speed can cause motor overload and needs to be adjusted within the rated range.

　　风压决定压力等级，需结合管道系统阻力计算。风压是克服阻力的压力，需计算管路总阻力，包括沿程阻力、局部阻力及设备阻力，并预留一定余量。罗茨鼓风机风压与转速无关，由叶轮间隙和电机功率决定，同一型号风压固定，选型时需按总阻力选对应压力等级，过高增加能耗，过低无法完成输送。

　　The wind pressure determines the pressure level, which needs to be calculated in conjunction with the resistance of the pipeline system. Wind pressure is the pressure that overcomes resistance, and the total resistance of the pipeline needs to be calculated, including resistance along the way, local resistance, and equipment resistance, with a certain margin reserved. The wind pressure of Roots blower is independent of the speed and is determined by the impeller clearance and motor power. The wind pressure of the same model is fixed. When selecting, the corresponding pressure level should be selected according to the total resistance. If it is too high, it will increase energy consumption, and if it is too low, it will not be able to complete the conveying.

　　电机功率需与风量、风压匹配。功率计算公式为（风量 × 风压）÷（效率 ×102），效率取 0.7-0.85，选型时电机功率应略高于计算值。功率过大会增加投资和空载能耗，过小则导致电机过载。需按电源条件选电机类型，大功率用三相 380V 电源，小功率可用单相 220V，防爆环境需选防爆电机。

　　The motor power needs to be matched with the air volume and pressure. The power calculation formula is (air volume x air pressure) ÷ (efficiency x 102), with an efficiency of 0.7-0.85. When selecting, the motor power should be slightly higher than the calculated value. Excessive power will increase investment and no-load energy consumption, while insufficient power will cause motor overload. The motor type should be selected according to the power supply conditions. For high power, a three-phase 380V power supply can be used, while for low power, a single-phase 220V power supply can be used. Explosion proof motors should be selected for explosion-proof environments.

　　结构与材质要适配应用环境。普通型适用于干燥清洁气体，水冷型适合高温或高转速工况。铸铁材质成本低、强度高，适用于无腐蚀性场合；不锈钢耐腐蚀性好，适合潮湿或轻度腐蚀性环境；特殊涂层风机可用于中等腐蚀性环境。

　　The structure and material should be adapted to the application environment. The regular type is suitable for dry and clean gases, while the water-cooled type is suitable for high temperature or high-speed working conditions. Cast iron material has low cost and high strength, suitable for non corrosive applications; Stainless steel has good corrosion resistance and is suitable for humid or mildly corrosive environments; Special coated fans can be used in moderately corrosive environments.

　　运行效率与能耗影响长期成本。风机在额定风量 70%-90% 区间效率最高，选型应让实际风量处于此区间。配备变频调速装置可降低能耗，尤其适合风量波动大的场景。同时要考虑维护成本，超负荷运行会缩短易损件更换周期。

　　The operational efficiency and energy consumption have an impact on long-term costs. The fan has the highest efficiency in the range of 70% -90% of the rated air volume, and the selection should ensure that the actual air volume is within this range. Equipped with a variable frequency speed regulation device can reduce energy consumption, especially suitable for scenarios with large fluctuations in air volume. At the same time, maintenance costs should be considered, as overloading operation will shorten the replacement cycle of vulnerable parts.

　　安装与适配性也需关注。按风机尺寸预留安装和检修空间，管道连接匹配进出口尺寸，法兰连接要密封良好，安装柔性接头减少振动影响，并装压力表等监测装置。普通风机运行噪声 85-100 分贝，居民区附近需配消声器或隔声罩。

　　Installation and adaptability also need to be considered. Reserve installation and maintenance space according to the size of the fan, match the inlet and outlet sizes for pipeline connections, ensure good sealing for flange connections, install flexible joints to reduce vibration effects, and install monitoring devices such as pressure gauges. The operating noise of ordinary fans is 85-100 decibels, and mufflers or soundproof enclosures need to be installed near residential areas.

　　罗茨鼓风机选型是系统过程，以风量、风压为基础，结合电机功率、材质等因素，兼顾安装条件与运行成本。科学选型能保证生产需求，降低能耗，延长寿命，为各行业提供可靠气源保障，必要时可参考性能曲线或进行现场测试。

　　The selection of Roots blower is a systematic process, based on air volume and pressure, combined with factors such as motor power and material, taking into account installation conditions and operating costs. Scientific selection can ensure production demand, reduce energy consumption, extend lifespan, and provide reliable gas source guarantee for various industries. When necessary, performance curves can be referenced or on-site testing can be conducted.
